Specifications
OSCAR Technical Manual V2.4.0
23
Oscar F-510C
Feature Specification
Image device Type 2/3 (diag. 11 mm) frame readout SONY CCD ICX-282AQ with
HAD microlens
Chip size 9.74 mm x 7.96 mm
Cell Size 3.4 µm x 3.4 µm
Picture size (max.) 2588 x 1958 pixels (Format_7 Mode_0)
Lens mount C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)
adjustable from 17.3 mm to 22.5 mm
Mechanical flange back to filter distance: 10.5 mm
(see Figure 9: Oscar C-Mount dimensions (standard filter) on page
33)
ADC 12 bit
Color modes Mono8; Y8-green, Y8-red, Y8-blue; RAW8/16; RGB8; YUV4:2:2;
YUV4:1:1
Frame rates 1.875 fps; 3.75 fps; 7.5 fps
Up to 3.8 fps in Format_7 frame readout
Up to 7.59 fps in Format_7 progressive
Gain control Manual: 0-20 dB (0.035 dB/step); auto gain (select. AOI)
Shutter speed 94 µs …67.108.864 µs (~67s); auto shutter (select. AOI)
External trigger shutter Trigger Mode_0, Trigger_Mode_1 (progressive scan, Format_7
Mode_0); advanced feature: Trigger_Mode_15 (bulk); image transfer
by command; trigger delay
Internal FIFO memory 32 MByte, optional up to 256 MByte
Look-up tables One, user programmable (12 bit 8/12 bit); gamma (0.5)
Smart functions Real time shading correction, High SNR mode (image summation),
image mirror (L-R Q R-L), sub-sampling, binning, user profiles
AWB (auto white balance), color correction, hue, saturation,
Two configurable inputs, two configurable outputs
RS-232 port (serial port, IIDC V1.31)
Transfer rate 100 Mbit/s, 200 Mbit/s, 400 Mbit/s
Digital interface IEEE 1394a IIDC v. 1.3
Power requirements DC 8 V - 36 V via IEEE 1394 cable or 12-pin HIROSE
Power consumption 3.6 watt (@ 12 V DC)
Dimensions 72.5 mm x 44 mm x 44 mm (L x W x H); without tripod and lens
Table 7: Specification Oscar F-510C
