Video formats, modes and bandwidth
OSCAR Technical Manual V2.4.0
127
Video formats: Oscar F-810C
[1] Camera outputs RAW image which needs to be converted outside of camera.
[2] Camera outputs interpolated B/W image using luma interpolation formula.
[3] Camera outputs interpolated B/W image using one of the R-G-B color planes.
[4] Only achievable with shutter settings that don't exceed 1/framerate.
Format Mode Resolution Color mode 60
fps
30
fps
[4]
15
fps 7.5
fps 3.75
fps 1.875
fps
1
0 800 x 600 YUV422
1 800 x 600 RGB8
2 800 x 600 MONO8
3 1024 x 768 YUV422 x x
4 1024 x 768 RGB8 x x
5 1024 x 768 MONO8
x
[2]
x
[2]
6 800 x 600 MONO16
7 1024 x 768 MONO16
Table 48: Fixed video formats Oscar F-810C (frame readout, centered)
Format Mode Resolution Color mode Frame rate / fps Description
7 0 3272 x 2469
Mono8
[2]
3.15
frame readout
joint shutter
YUV411 2.70
YUV422 2.03
RGB8 1.35
Raw8
[1]
3.15
Raw16
[1]
2.03
Y8red, Y8green, Y8blue
[3]
3.15
7 1 3272 x 2469
Mono8
[2]
3.15
frame readout
split shutter
YUV411 2.70
YUV422 2.03
RGB8 1.35
Raw8
[2]
3.15
Raw16
[1]
2.03
Y8red, Y8green, Y8blue
[3]
3.15
Table 49: Format_7 video formats Oscar F-810C
