Video formats, modes and bandwidth
OSCAR Technical Manual V2.4.0
120
Video formats, modes and bandwidth
The different Oscar models support different video formats, modes and frame
rates.
These formats and modes are standardized in the IIDC (formerly DCAM) spec-
ification.
Resolutions in Format_0, Format_1 and Format_2, which are smaller than the
generic sensor resolution, are generated symmetrically from the center of the
sensor and without binning.
Different color processing modes in Format_7 are accessed via
Color_Coding_ID register, as listed for Oscar F-510C.
Binning modes are only available in Format_7 for Oscar F-510C:
• Format_7 Mode_5: horizontal binning (H-binning)
• Format_7 Mode_6: vertical binning (V-binning)
• Format_7 Mode_7: horizontal and vertical binning (H+V binning)
Note
L
• The maximum frame rates can only be achieved with
shutter settings lower than 1/framerate. This means
that with default shutter time of 40 ms, a camera will
not achieve frame rates higher than 25 frames/s. In
order to achieve higher frame rates, please reduce the
shutter time proportionally.
• The following tables assume that bus speed is
400 Mbit/s. With lower bus speeds (e.g. 200 or 100
Mbit/s) not all frame rates may be achieved.
• For information on bit/pixel and byte/pixel for each
color mode see
Table 92: ByteDepth on page 215.
Note
L
H-binning means horizontal binning.
V-binning means vertical binning.
Full binning (H+V) means horizontal + vertical binning
2 x binning means: 2 neighboring pixels are combined.
• Binning increases signal-to-noise ratio (SNR), but
decreases resolution.
