Specifications
OSCAR Technical Manual V2.4.0
25
Oscar F-810C
Feature
Specification
Image device
Type 2/3 (diag. 11.07 mm) frame readout SONY CCD ICX-456AQ with
HAD microlens
Chip size
9.79 mm x 7.93 mm
Cell size
2.7 µm x 2.7 µm
Picture size (max.)
3272 x 2469 pixels (Format_7 Mode_0)
Lens mount
C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)
adjustable from 17.3 mm to 22.5 mm
Mechanical flange back to filter distance: 10.5 mm
Figure 9: Oscar C-Mount dimensions (standard filter)
ADC
12 bit
Color modes
Mono8; Y8-green, Y8-red, Y8-blue; Raw8/16; RGB8; YUV422;
YUV411
Frame rates
3.75 fps; 7.5 fps
Up to 3.15 fps in Format_7 frame readout
Up to 8.88 fps in Format_7 progressive
Gain control
Manual: 0-20 dB (0.035 dB/step); auto gain (select. AOI)
Shutter speed
118 µs …67.108.864 µs (~67s); auto shutter (select. AOI)
External trigger shutter
Trigger Mode_0, Trigger_Mode_1 (progr. scan, Format_7 Mode_0);
advanced feature: Trigger_Mode_15 (bulk); image transfer by com-
mand; trigger delay
Internal FIFO memory
64 MByte, optional up to 256 MByte
Look-up tables
One, user programmable (12 bit
8/12 bit); gamma (0.5)
Smart functions
Real time shading correction, High SNR mode (image summation),
image mirror (L-R Q R-L), sub-sampling, user profiles
AWB (auto white balance), color correction, hue, saturation
Two configurable inputs, two configurable outputs
RS-232 port (serial port, IIDC V1.31)
Transfer rate
100 Mbit/s, 200 Mbit/s, 400 Mbit/s
Digital interface
IEEE 1394a IIDC v. 1.3
Power requirements
DC 8 V - 36 V via IEEE 1394 cable or 12-pin HIROSE
Power consumption
3.6 watt (@ 12 V DC)
Dimensions
72.5 mm x 44 mm x 44 mm (L x W x H); without tripod and lens
Table 8: Specification Oscar F-810C
