Video formats, modes and bandwidth
OSCAR Technical Manual V2.4.0
126
The different color modes in Format_7 modes are controlled via the
COLOR_CODING_ID register in combination with COLOR_CODING_INQ regis-
ter.
[1] Camera outputs RAW image which needs to be converted outside of camera.
[2] Camera outputs interpolated B/W image using luma interpolation formula.
[3] Camera outputs interpolated B/W image using one of the R-G-B color planes.
[4] Only achievable with shutter settings that don't exceed 1/framerate.
Offset
Name
Field
Bit
Notes
F0F08010h
FORMAT_7_MODE_0
COLOR_CODING_ID
Coding_ID
[0..7]
Color coding ID from
COLOR_CODING_INQ register
F0F08014h
F_7M_0 COLOR_CODING_INQ
Mono8
[0]
ID=0
YUV 411
[1]
ID=1
YUV 422
[2]
ID=2
RGB8
[4]
ID=4
RAW8
[9]
ID=9
RAW16
[10]
ID=10
F0F08024h
Y8red
[0]
ID=128
Y8green
[1]
ID=129
Y8blue
[2]
ID=130
F0F09010h
F_7M_1 COLOR_CODING_ID
Same for Mode_1
F0F09014h
F_7M_1 COLOR_CODING_INQ
Same for Mode_1
F0F0A010h
F_7M_2 COLOR_CODING_ID
Same for Mode_2
F0F0A014h
F_7M_2 COLOR_CODING_INQ
Same for Mode_2
F0F0B010h
F_7M_3 COLOR_CODING_ID
Same for Mode_3
F0F0B014h
F_7M_3 COLOR_CODING_INQ
Same for Mode_3
F0F0C010h
F_7M_4 COLOR_CODING_ID
Same for Mode_4
F0F0C014h
F_7M_4 COLOR_CODING_INQ
Same for Mode_4
Table 47: Color coding inquiry and IDs
