Configuration of the camera
OSCAR Technical Manual V2.4.0
195
Color correction
To switch off color correction in YUV mode: see bit [6]
Trigger delay
The advanced register allows start of the integration to be delayed via
DelayTime by max. 2
21
µs, which is max. 2.1 s after a trigger edge was
detected.
Register Name Field Bit Description
0xF10003A0 COLOR_CORR ON_OFF [6] Color correction on/off
default: on
Write: 02000000h to switch
color correction OFF
Write: 00000000h to switch
color correction ON
Table 97: Advanced register: Color correction
Register Name Field Bit Description
0xF1000400 TRIGGER_DELAY Presence_Inq [0] Indicates presence of this
feature (read only)
--- [1..5] Reserved
ON_OFF [6] Trigger delay on/off
--- [7..10] Reserved
DelayTime [11..31] Delay time in µs
Table 98: Advanced register: Trigger delay
