Video formats, modes and bandwidth
OSCAR Technical Manual V2.4.0
133
Format Mode Resolution Color mode 60
fps
30
fps 15
fps 7.5
fps 3.75
fps 1.875
fps
1
0 800 x 600
16 bit/pixel
YUV (4:2:2) 5/2H
2000p
1000q 5/4H
1000p
500q 5/8H
500p
250q 6/16H
250p
125q
1 800 x 600
24 bit/pixel
RGB 5/4H
1000p
750q 5/8H
500p
375q
2 800 x 600
8 bit/pixel
Y (MONO8) 5H
4000p
1000q 5/2H
2000p
500q 5/4H
1000p
250q 5/8H
500p
125q
3 1024 x 768
16 bit/pixel
YUV (4:2:2) 3/2H
1536p
768q 3/4H
768p
384q 3/8H
384p
192q 3/16H
192p
96q
4 1024 x 768
24 bit/pixel
RGB 3/4H
768p
576q 3/8H
384p
288q 3/16H
192p
144q
5 1024 x 768
8 bit/pixel
Y (MONO) 3H
3072p
768q 3/2H
1536p
384q 3/4H
768p
192q 3/8H
384p
96q 3/16H
192p
48q
6 800 x 600
16 bit/pixel
(MONO16) 5/2H
2000p
1000q 5/4H
1000p
500q 5/8H
500p
250q 5/16H
250p
125q
7 1024 x 768
16 bit/pixel
Y (MONO16) 3/2H
1536p
768q 3/4H
768p
384q 3/8H
384p
192q 3/16H
192p
96q
Table 53: Format_1
