Configuration of the camera
OSCAR Technical Manual V2.4.0
174
00Ch IMAGE_SIZE According to IIDC V1.3
010h COLOR_CODING_ID See note
014h COLOR_CODING_INQ According to IIDC V1.3
034h PIXEL_NUMER_INQ According to IIDC V1.3
038h TOTAL_BYTES_HI_INQ According to IIDC V1.3
03Ch TOTAL_BYTES_LO_INQ According to IIDC V1.3
040h PACKET_PARA_INQ See note
044h BYTE_PER_PACKET According to IIDC V1.3
Note
L
• For all modes in Format_7, ErrorFlag_1 and
ErrorFlag_2 are refreshed on each access to the
Format_7 register.
• Contrary to IIDC V1.3, registers relevant to Format_7
are refreshed on each access. The Setting_1 bit is
automatically cleared after each access.
• When ErrorFlag_1 or ErrorFlag_2 are set and Format_7
is configured, no image capture is started.
• Contrary to IIDC v.1.3, COLOR_CODING_ID is set to a
default value after an INITIALIZE or reset.
• Contrary to IIDC V1.3, the UnitBytePerPacket field is
already filled in with a fixed value in the
PACKET_PARA_INQ register.
Offset Name Notes
Table 79: Format_7 control and status register
