Video formats, modes and bandwidth
OSCAR Technical Manual V2.4.0
128
[1] Camera outputs RAW image which needs to be converted outside of camera.
[2] Camera outputs interpolated B/W image using luma interpolation formula.
[3] Camera outputs interpolated B/W image using one of the R-G-B color planes.
[4] Only achievable with shutter settings that don't exceed 1/framerate.
7 2 1088 x 822
Mono8
[2]
8.86
progressive scan
sub-sampling
YUV411 8.88
YUV422 8.88
RGB8 8.88
Raw8
[1]
8.86
Raw16
[1]
8.88
Y8red, Y8green, Y8blue
[3]
8.86
Format Mode Resolution Color mode Frame rate / fps Description
Table 49: Format_7 video formats Oscar F-810C
