How does bandwidth affect the frame rate?
OSCAR Technical Manual V2.4.0
143
Example formula for the Oscar F-810C camera
RGB8, 3272 x 2496 pixel, 2 fps desired
Test images
Loading test images
Formula 14: Example maximum frame rate calculation
FirePackage Fire4Linux
1. Start SmartView.
2. Click the Edit settings button.
3. Click Adv1 tab.
4. In combo box Test images
choose Image 1 or another test
image.
1. Start cc1394 viewer.
2. In Adjustments menu click on
Picture Control.
3. Click Main tab.
4. Activate Test image check box
on.
5. In combo box Test images
choose Image 1 or another test
image.
Table 62: Loading test images in different viewers
BYTE_PER_PACKET 2 3272
Ч
2469
Ч
3
Ч
125µs
×
6004 4096
> = =
framerate
reachable
4096
3272 2469
Ч
3
Ч
125µs
Ч
------------------------------------------------------------
1.35 = ≈ ⇒
