Configuration of the camera
OSCAR Technical Manual V2.4.0
173
Feature control error status register
Video mode control and status registers for
Format_7
Quadlet offset Format_7 Mode_0
The quadlet offset to the base address for Format_7 Mode_0, which can be
read out at F0F002E0h (according to
Table 72: Frame rate inquiry register on
page 153) gives 003C2000h.
4 x 3C2000h = F08000h so that the base address for the latter ( Table 79:
Format_7 control and status register on page 173) equals to
F0000000h + F08000h = F0F08000h.
Quadlet offset Format_7 Mode_1
The quadlet offset to the base address for Format_7 Mode_1, which can be
read out at F0F002E4h (according to
Table 72: Frame rate inquiry register on
page 153) gives 003C2400h.
4 x 003C2400h = F09000h so that the base address for the latter ( Table 79:
Format_7 control and status register on page 173) equals to
F0000000h + F09000h = F0F09000h.
Format_7 control and status register (CSR)
Offset Name Notes
640h Feature_Control_Error_Status_HI Always 0
644h Feature_Control_Error_Status_LO Always 0
Table 78: Feature control error register
Note
L
Color_Coding_ID and Inq is important for the various (above
standard) color modes of the OSCAR cameras and is explained
in Chapter
Video formats, modes and bandwidth on page 120.
Offset Name Notes
000h MAX_IMAGE_SIZE_INQ According to IIDC V1.3
004h UNIT_SIZE_INQ According to IIDC V1.3
008h IMAGE_POSITION According to IIDC V1.3
Table 79: Format_7 control and status register
