Camera interfaces

OSCAR Technical Manual V2.4.0

50

The following table provides a description of the video data format for the
different modes. (Source: IIDC V1.3)

Figure 17: YUV 4:2:2 and YUV 4:1:1 format: Source: IIDC V1.3

Figure 18: Y8 and Y16 format: Source: IIDC V1.3
