Blink codes are used to signal warnings or error states:
The longer OFF-time of 3.5 sec. signals the beginning of a new class period.
The error codes follow after a shorter OFF-time of 1.5 sec.
Example 3.5 sec. one blink 1.5 sec. 2 blinks
indicates a warning: Format_7_Error_1
Class S1
Error codes S2
Warning
1 blink DCAM
2 blinks MISC
3 blinks FPGA
4 blinks Stack
5 blinks
FPGA boot error 1-5 blinks
Stack setup 1 blink
Stack start 2 blinks
No FLASH object 1 blink
No DCAM object 1 blink
Register mapping 2 blinks
VMode_ERROR_STATUS 1 blink
FORMAT_7_ERROR_1 2 blinks
FORMAT_7_ERROR_2 3 blinks
Table 10: Error codes
