Description of the data path
OSCAR Technical Manual V2.4.0
72
Note
L
• The input value is the most significant 12-bit value
from the digitizer. The gamma LUT outputs the most
significant 8 bit as shown above.
• As gamma correction is also implemented via the LUT,
it is not possible to use a different LUT when gamma
correction is enabled.
• After overriding the LUT with a user defined content,
gamma functionality is no longer available until the
next full initialization of the camera.
• LUT content is volatile if you do not use the user pro-
files to save the LUT.
