Configuration of the camera
OSCAR Technical Manual V2.4.0
149
420h + 000002h x 4 = 428h
The entry with key D1 in the root directory (424h in this case) provides the
offset for the unit directory as follows:
424h + 000004h x 4 = 434h
The entry with key D4 in the unit directory (440h in this case) provides the
offset for unit dependent info:
440h + 000001h * 4 = 444h
To compute the effective start address of the node unique ID leaf
currAddr
= node unique ID leaf address
destAddr
= address of directory entry
addrOffset
= value of directory entry
destAddr
= currAddr + (4 x addrOffset)
= 420h + (4 x 000002h)
= 428h
Table 65: Computing effective start address
Offset
0-7
8-15
16-23
24-31
428h
00
02
CA
71
Node unique ID leaf
42Ch
00
0A
47
01
430h
00
00
Serial number
Table 66: Configuration ROM
Offset
0-7
8-15
16-23
24-31
434h
00
03
93
7D
Unit directory
438h
12
00
A0
2D
43Ch
13
00
01
02
440h
D4
00
00
01
Table 67: Configuration ROM
