Page 9
9
746-257-B2-001, Rev. B (01/2014)
Intelligent CableUPS
Interface (other side)
Fig. 1-3, Side view, AlphaNet IDH4 Series
1.0 Introduction
RF Connector
Ethernet Port for Local Diagnostics
Tamper Connector
Environmental IO Connector
Battery Monitoring Connection A/B
(IDH4 and IDH4X only)
COM Port (IDH4X only)
Battery Monitoring Connection C/D
(IDH4X only)
