72 746-257-B2-001, Rev. B (01/2014)
10.1 Definitions and Settings
10.0 Alpha MIB Parameters
Parameter OID Description Access Type Value
COMMUNITY STRINGS
atiMgntSnmpCommunities 1.3.6.1.4.1.926.1.3.1.4.0 Object Identifier
atiMgmtSnmpCommGet 1.3.6.1.4.1.926.1.3.1.4.1.0 Default "Read" Community String Read/Write Octet String AlphaGet (default
atiMgmtSnmpCommSet 1.3.6.1.4.1.926.1.3.1.4.2.0 Default "Read/Write" Community String Read/Write Octet String AlphaSet (default)
SNMP TRAP
atiMgmtSnmpControls 1.3.6.1.4.1.926.1.3.1.5 Object Identifier
atiMgmtSnmpTrapOnNormal 1.3.6.1.4.1.926.1.3.1.5.1.0 Traps sent when an item in an alarm
state returns to normal.
Read/Write Integer 1 = Disable
2 = Enable (Default)
atiMgmtSnmpSendCount 1.3.6.1.4.1.926.1.3.1.5.2.0 Number of times a trap is to be sent/
repeated.
Read/Write Integer 1 to 9
1 (Default)
atiMgmtSysSnmpTimeout 1.3.6.1.4.1.926.1.3.1.5.3.0 The number of minutes allowed to pass
without SNMP communications. On the
lapse of this many minutes the device
will reset. Setting this value to zero will
prevent timeout resets.
Read/Write Integer 0 to 65,000 (in minutes)
1440 (Default)
WEB SERVER ENABLE
atiMgmtSysHttpPrams
1.3.6.1.4.1.926.1.3.2.2.4 Object Identifier
atiMgmtSysHttpEnabled 1.3.6.1.4.1.926.1.3.2.2.4.1.0 Access to IDH4 via Web Browser Read/Write Integer 1=Disable
2=Enable (default)
SIMPLE NETWORK TIME PROTOCOL
atiMgmtSysServers 1.3.6.1.4.1.926.1.3.2.3.0 Object Identifier
atiMgmtSysServSntp 1.3.6.1.4.1.926.1.3.2.3.1.0 IP Address of SNTP Server (Optional) Read/Write IP Address 0.0.0.0 (Default)
ENVIRONMENTAL MANAGER
atiMgmtSysTempMgr 1.3.6.1.4.1.926.1.3.2.4.0 Object Identifier
atiMgmtSysTempCtrl 1.3.6.1.4.1.926.1.3.2.4.1.0 Environmental Control Read/Write Integer 1=off (Default)
2=OnTimer
3=OnTemp
4=onTimerTemp
5=on
atiMgmtSysTempStatus 1.3.6.1.4.1.926.1.3.2.4.2.0 Environmental Control Feedback State Read Only Integer 1=Contact Open (default)
2=Contact Closed
atiMgmtSysTempMode 1.3.6.1.4.1.926.1.3.2.4.3.0 Environmental Mode (Heat/Cool) Read/Write Integer 1=Heater (Default)
2=Cooler
atiMgmtSysTempActiveState 1.3.6.1.4.1.926.1.3.2.4.4.0 Environmental Control Contact State
(Open/Closed)
Read/Write Integer 1=Closed (Default)
2=Open
atiMgmtSysTempTemperature 1.3.6.1.4.1.926.1.3.2.4.5.0 Environment Temperature Read/Write Integer 1..70ºC
atiMgmtSysTempHysteresis 1.3.6.1.4.1.926.1.3.2.4.6.0 Environmental Temperature Hysteresis Read/Write Integer 1..10ºC
atiMgmtSysTempTimer 1.3.6.1.4.1.926.1.3.2.4.7.0 Environmental Default Timer Read/Write Integer 0..1440 (30 Minute Default, 15
minute increments)
atiMgmtSysTempCountdown 1.3.6.1.4.1.926.1.3.2.4.8.0 Environmental Timer Time Remaining Read Only Integer 0..1440 (in minutes)
atiMgmtSysTempStatusInvert 1.3.6.1.4.1.926.1.3.2.4.9.0 State Inverted to match the type of relay
operation on the heater mat controller
Read/Write Integer 1=No invert (Default)
2=Invert
PHONE HOME MANAGER
atiMgmtSysPhoneHomeIp
1.3.6.1.4.1.926.1.3.2.5 Object Identifier
atiMgmtSysPhoneHomeIp 1.3.6.1.4.1.926.1.3.2.5.1.0 Address for the Phone Home Frame Read/Write IP Address 0.0.0.0
atiMgmtSysPhoneHomeForce 1.3.6.1.4.1.926.1.3.2.5.2.0 Forces one Phone Home message
regardless of timers
Read/Write Integer 1=No Operation (default)
2=Force
atiMgmtSysPhoneHomeTimer 1.3.6.1.4.1.926.1.3.2.5.3.0 Time since last frame transmitted, zero
means never transmitted
Read Only Time Ticks
