45

746-257-B2-001, Rev. B (01/2014)

6.0 Data Management

Discrete Alarms

Description

Setting

psInverterStatus (1)

Inverter OFF

Disable

psInverterStatus (2)

Inverter running due to loss of AC Line voltage

discreteMinor

psInverterStatus (3)

Self Test initiated locally

Disable

psInverterStatus (4)

Self Test initiated remotely

Disable

psInverterStatus (5)

Last Self Test failed

discreteMajor

psMajorAlarm (1)

No Alarm

Disable

psMajorAlarm (2)

Alarm

discreteMajor

psMinorAlarm (1)

No Alarm

Disable

psMinorAlarm (2)

Alarm

discreteMinor

psTamper (1)

Closed

Disable

psTamper (2)

Open

discreteMajor

psInputVoltagePresence (1) AC Line Voltage Lost

Disable

psInputVoltagePresence (2) AC Line Voltage Present

Disable

tibControlMode (1)

Device will respond to commands

Disable

tibControlMode (2)

Device is under local control

Disable

tibControlMode (3)

Remote device is not responding

discreteMajor

Discrete Alarms for Optional Generator
genGeneratorStatus (1)

Generator Off

Disable

genGeneratorStatus (2)

Generator Running (Test)

discreteMinor

genGeneratorStatus (3)

Generator Running

discreteMajor

genGeneratorStatus (4)

Generator Fail

discreteMajor

genGasHazard (1)

No Alarm

Disable

genGasHazard (2)

The concentration of hydrocarbon fuel in the generator enclosure has exceeded safe

limits. Generator operation is suspended. The alarm is cleared when the sensor reports

safe conditions, and the alarm is reset via the resetLatchedAlarms(3) command found in

the genEquipmentControl MIB point..

discreteMajor

genWaterIntrusion (1)

No Alarm

Disable

genWaterIntrusion (2)

Water level within the generator or fuel enclosure has exceeded safe limits for generator

operation. Generator operation is suspended while this alarm is active. The alarm resets

when the water returns to a safe level.

discreteMajor

genPadShear (1)

No Alarm

Disable

genPadShear (2)

Indicates that the generator or fuel enclosure has shifted from its mounting position.

Generator operation is suspended. The alarm resets when the unit is returned to its

original position.

discreteMajor

genEnclosureDoor (1)

No Alarm

Disable

genEnclosureDoor (2)

Generator and/or auxiliary fuel enclosure door is open

discreteMajor

genCharger (1)

No Alarm

Disable

genCharger (2)

Ignition battery charger is not operating correctly

discreteMajor

genFuel (1)

No Alarm

Disable

genFuel (2)

Indicates the engine's fuel supply is insufficient for extended operation. Alarm resets

when fuel is replenished.

discreteMajor

genOil (1)

No Alarm

Disable

genOil (2)

Indicates the engine's oil is inadequate for safe operation. Alarm resets when the

condition returns to normal.

discreteMajor

genMinorAlarm (1)

No Alarm

Disable

genMinorAlarm (2)

The generator is indicating a minor alarm. The generator requires attention, but does not

require an immediate visit to the site.

discreteMinor

genMajorAlarm (1)

No Alarm

Disable

genMajorAlarm (2)

The generator is indicating a major alarm. The generator requires immediate attention.

discreteMajor

6.2.1 SCTE-HMS Configurable Alarms

Table 6-5, Recommended Settings for Discrete Alarms
