Specifications for AlphaNet IDH4 Family

IDH4X

IDH4

Power Supply Monitored Parameters

Major Alarm:

Aggregate alarm consisting of: test fail, battery fail, line isolation alarm, output overload, inverter,

over-temperature, N+1 active, fuse fail

Minor Alarm:

Aggregate alarm consisting of: temperature probe error, AC line loss, N+1 error

Input Voltage:

Reported from power supply V(in) measurement

Output Voltage:

Reported from power supply V(out) measurement

Output Current:

0 to 25A standard on port 1

Ports 2-4 require power supply option

Output Power:

Calculated, reported in AC Watts

UPS Status:

AC Line, Standby, Test in progress, Test alarm

Enclosure Door:

Open or Closed

Battery Voltage:

Individual battery voltage, up to four strings of 3 or 4

batteries (maximum 16 batteries),

±100mV per battery.

Individual battery voltage, up to two strings

of 3 or 4 batteries (maximum 8 batteries),

±100mV per battery.

Battery Temperature:

Reported from power supply battery Remote Temperature Sensor (RTS)

Remote Test Control:

Start/Stop power supply test cycle

Generator Monitored Parameters (IDH4X Only)

Status:

Generator Off, Running, Alarm

Generator Alarm:

Aggregate alarm consisting of: low oil pressure, engine over-temp, engine over-speed, crank limit,

over voltage, low fuel, water intrusion, pad shear, gas hazard, test fail

Gas Hazard:

OK, Alarm

Water Intrusion:

OK, Alarm

Pad Shear:

OK, Alarm

Enclosure Door:

OK, Alarm

Ignition Battery Voltage:

±100mV

Enclosure Temperature:

±2°C

Low Fuel:

OK, Alarm

Remote Test Control:

Start / Stop generator test cycle

Cable Modem

Compliance:

DOCSIS 1.1 and 2.0

Transmit Frequency Range:

5 to 42MHz

Receive Center Frequency Range:

91 to 857MHz

Output Power Range:

TDMA:

+8 to +54 dBmV (32QAM, 64QAM)

+8 to +55 dBmV (8QAM, 16QAM)

+8 to +58 dBmV (QPSK)

S-CDMA:

+8 to +53 dBmV (All modulations of S-CDMA)

Input Signal Range:

-15 to 15dBmV

Channel Bandwidth:

6MHz

Additional Equipment

874-842-21

Wire Kit, Battery Sense, 1x36V, 6'

874-842-20

Wire Kit, Battery Sense, 2x36V, 6'

874-841-21

Wire Kit, Battery Sense, 1x48V, 6'

874-841-20

Wire Kit, Battery Sense, 2x48V, 6'

162-028-10

Surge Protector: Female/Female connector configuration, “F” type connector with integral ground

block. Required for all installations.

12.0 Specifications
