74 746-257-B2-001, Rev. B (01/2014)
Parameter OID Description Access Type Value
SYSTEM ALARMS
atiBBSysViewAlarms
1.3.6.1.4.1.926.1.4.1.1.2 Object Identifier
atiBBSysViewMajorAlarm 1.3.6.1.4.1.926.1.4.1.1.2.1.0 Indicates if any of the items monitored are in a major
alarm state.
Read Only Integer 1=OK
2=Alarm
atiBBSysViewMinorAlarm 1.3.6.1.4.1.926.1.4.1.1.2.2.0 Indicates if any of the items monitored are in a minor
alarm state.
Read Only Integer 1=OK
2=Alarm
atiBBSysViewSelfTestResult 1.3.6.1.4.1.926.1.4.1.1.2.3.0 If any of the items being monitored indicate that
self-test failed, this item indicates a failure.
Read Only Integer 1=OK
2=Fail
atiBBSysViewTempProbeStatus 1.3.6.1.4.1.926.1.4.1.1.2.4.0 If any of the devices being monitored indicate a
temp probe failure or absence, this item will alarm.
Read Only Integer 1=OK
2=Missing
atiBBSysViewInputStatus 1.3.6.1.4.1.926.1.4.1.1.2.5.0 If ALL the items being monitored indicate no AC, this
item will alarm.
Read Only Integer 1=OK
2=No AC Present
SCALARS
atiBBSysViewScalars
1.3.6.1.4.1.926.1.4.1.1.3 Object Identifier
atiBBSysViewInputVoltage 1.3.6.1.4.1.926.1.4.1.1.3.1.0 Power supply input voltage. Read Only Integer
atiBBSysViewInputFrequency 1.3.6.1.4.1.926.1.4.1.1.3.2.0 Power supply input line frequency. Read Only Integer
atiBBSysViewInputCurrent 1.3.6.1.4.1.926.1.4.1.1.3.3.0 Power supply input current. Read Only Integer
atiBBSysViewBatteryVoltage 1.3.6.1.4.1.926.1.4.1.1.3.4.0 Battery voltage. Read Only Integer
atiBBSysViewBatteryTemperature 1.3.6.1.4.1.926.1.4.1.1.3.5.0 Battery temperature (Degrees C). Read Only Integer
atiBBSysViewChargerCurrent 1.3.6.1.4.1.926.1.4.1.1.3.6.0 Sum of charging current from all power supplies. Read Only Integer
atiBBSysViewChargerVoltsFloat 1.3.6.1.4.1.926.1.4.1.1.3.7.0 Battery charger float voltage. Read/Write Integer
atiBBSysViewChargerVoltsEqualize 1.3.6.1.4.1.926.1.4.1.1.3.8.0 Battery charger equalization voltage. Read/Write Integer
atiBBSysViewChargerVoltsTemperatureComp 1.3.6.1.4.1.926.1.4.1.1.3.9.0 Battery charger temperature compensation
(0 to 5mV/Cell/°C). Read/Write Integer
atiBBSysViewBatteryCapacity 1.3.6.1.4.1.926.1.4.1.1.3.10.0 Battery string capacity (Amp hours). Read/Write Integer
SCALARS
atiBBSysViewCounters
1.3.6.1.4.1.926.1.4.1.1.4 Object Identifier
atiBBSysViewSelfTestInterval 1.3.6.1.4.1.926.1.4.1.1.4.1 Number of days between automated self tests Read-Write Integer 0..65535
atiBBSysViewSelfTestCountdown 1.3.6.1.4.1.926.1.4.1.1.4.2 Number of days until the next automated self test Read-Write Integer 0..65535
atiBBSysViewSelfTestDuration 1.3.6.1.4.1.926.1.4.1.1.4.3 Number of minutes for which an automated self
test will run
Read-Write Integer 0..65535
atiBBSysViewInverterRuntime 1.3.6.1.4.1.926.1.4.1.1.4.4 Number of minutes the inverter has run due to an
AC fail event
Read Only Integer 0..65535
atiBBSysViewStandbyEvents 1.3.6.1.4.1.926.1.4.1.1.4.5 Number of times the inverter has gone into standby
due to an AC fail event
Read Only Integer 0..65535
atiBBSysViewRuntimeRemaining 1.3.6.1.4.1.926.1.4.1.1.4.6 Seconds of estimated runtime remaining when in
standby
Read Only Integer 0..65535
atiBBSysViewTimeInStandby 1.3.6.1.4.1.926.1.4.1.1.4.7 Seconds. If currently in standby, time in standby. If
not in standby this value will be zero
Read Only Integer 0..-1
atiBBSysViewTimeSinceLastStandby 1.3.6.1.4.1.926.1.4.1.1.4.8 Seconds. The accumulated time since the end of
last standby event and the start of the next standby
event. The counter will reset to zero after the next
standby event has ended.
Read Only Integer 0..-1
atiBBSysViewTimeInLastStandby 1.3.6.1.4.1.926.1.4.1.1.4.9 Seconds. The length (time) of last standby event.
If currently in a standby event this value will be the
length of the previous standby event. This value will
be updated at the conclusion of each standby event.
This item is saved in non-vol memory.
Read Only Integer 0..-1
DETECT 6V BATTS
atiCibDiscTable
1.3.6.1.4.1.926.1.2.1.1.1.5.14.0.11 Controls the ability to detect and report 6 Volt
batteries.
Read/Write Integer 0 = default
1 = Detect 6 Volt
Batteries
10.1 Definitions and Settings
10.0 Alpha MIB Parameters
