80

746-257-B2-001, Rev. B (01/2014)

11.0 Dual IP Mode

11.3

Configuring Dual IP Mode, continued

11.3.1 atidoc03.cfg in Dual IP Mode

In Dual IP mode, the Transponder will first attempt to download the proprietary configuration

file atidoc03.cfg through the CPE’s interface from a TFTP server on the CPE network. In many

networks, the TFTP server is blocked or disabled, so the transponder also has provisions to

download this file through the Cable Modem interface from the modem’s provisioning server if

necessary. The filename and TFTP server location may also be specified through special tags
in the DHCP Offer, refer to

Section 13.3.3, Specifying atidoc03.cfg Name and Location via

DHCP Tags for details. Similiar to Single IP mode, any IDH4 proprietary SNMP MIB setting may

be placed in the modem’s DOCSIS configuration file which would eliminate the need for atidoc03.

cfg.

11.3.2 Changing Default atidoc03.cfg Download Settings in Dual IP Mode

The following table explains the download options available for the atidoc03.cfg file in Dual IP

mode. The ‘Download Interface’ indicates the network from which the transponder will attempt to

download atidoc03.cfg, either the CPE network or the more secure cable modem management
network.

Parameter

Comments

Value

Search

Order

Download

Interface

atiMgmtSysDownloadConfigAddress

OID 1.3.6.1.4.1.926.1.3.2.1.10.0

Overrides Default Location

0.0.0.0 (Default)

1

CPE

DHCP Server IP

Server or Relay Agent Address

from DHCP lease (No Change

Necessary)

As Set

2

CPE

DHCP Option 54 Server IP

Server or Relay Agent Address

from DHCP lease

As Set

3

CPE

DHCP Tags

See Section 13.3.3

As Set

4

CPE

docsDevServerConfigTftpAddress

1.3.6.1.2.1.69.1.4.11.0

Automatically set in modem

CM's TFTP Server

Address

5

CM

docsDevSwServerAddress

1.3.6.1.2.1.69.1.3.7.0

Set via DOCSIS configuration file

As Set

6

CM

Software Upgrade Server

Set via DOCSIS configuration file

As Set

7

CM

Refer to

Section 3.3.5 for details on using the atidoc03.cfg file to propagate custom settings to

field-deployed IDH4x or IDH4L Communications Modules.

NOTE:

Table 11-4, Download Options
