TP-6482 8/06 14 Section 1 Specifications
Front View
Right Side View
Left Side View
1 2 3 4
8
14 15
5
11
10
13
6
12
22
21
7
20
17
19
16 18
23
9
1. Engine interface connector
2. Engine starting battery connector
3. Ignition module
4. Engine oil fill and dipstick
5. Ignition coil
6. Spark plug
7. Fuel supply connection
8. High temperature (HET) sensor
9. DC output connector
10. Fuel block
11. Secondary fuel pressure regulator
12. Hourmeter location
13. Fuel metering valves, sealed
14. Oil filter
15. Exhaust pipe connection
16. Governor
17. Engine oil cooler
18. Alternator (inside)
19. Low oil pressure (LOP) switch
20. Oil drain
21. Carburetor
22. Air cleaner
23. Throttle linkage
ADV-6536-A
Figure 1-5 Alpha 5
