19 Firmware display of wireless PCB
77
System
Maximum number
Version 1 Version 1
3x virtual zones 3x PIR IP network
cameras 1x IP alarm module + 1x PIR
IP network camera
3x wireless zones 3 zones with a total of 11
detectors (4/3/4
detectors per zone) 3 zones with a total of 10
detectors (3/3/4 detectors
per zone) + 1x external siren
2x wireless outputs For any number of wireless sockets per output
1x relay output To control wired components
4x transistor outputs To trigger diallers
Operating units Max. 3 parts, wireless remote operation, Secvest key or
additional door lock (any combination possible)
Internal sirens Any number
19. Firmware display of wireless PCB
When the alarm centre is connected to the power supply, a start routine is run
through the centre. First of all, LEDs light up briefly and then the firmware status of
the PCB is issued via dual coding.
Firmware of wireless PCB
First display Second display Firmware status
LED in first place from the
bottom lights up briefly
LED in fourth place from
the bottom lights up briefly
1.8
LED in second place from
the bottom lights up briefly
LED in second place from
the bottom lights up briefly
2.2
You can easily see the software status of the IP PCB via the web server.
“System
Æ Maintenance Æ Firmware version“
20. Information on additional ABUS products
You can deal with any problems concerning the wireless range by using the repeater
function of the Secvest 2WAY wireless universal module (FU8210). Read the user
manual for the universal module.
21. Notes on maintenance
Set the alarm centre to learn mode when carrying out maintenance. You can then
open the alarm centre or teach wireless components (or change the battery) without
triggering a tamper alarm.
This is made using the web server: “System
Æ Maintenance Æ Learn Mode Æ ON”
