ABUS AZ6302 Terxon GSM dialer User Manual
Page 91
91
The GSM number of the SIM card is shown here. However,
some SIM card manufacturers do not support this function!
-
IMEI Number
The IMEI shows the special GSM device number.
-
IMSI Number
The IMSI shows the special SIM card number.
-
Device Type
The inserted GSM service module is displayed here.
-
Call Provider
The service provider of the inserted GSM card is displayed
here.
10. Press
to return to the main menu.
10.7 Software Version
The current GSM dialer software version is displayed here.
5. Enter your user code. Scroll through the menu options using the
keys, or alternatively press
to display the “Test Options” menu
point.
↑↓ ENT to select
Test Options
Confirm by pressing
. The first function is displayed: “Messages”.
6. Access the “Software Version” option using the
scroll keys, or
alternatively press the
key.
7. Press
. The display now shows the current software version.
Version 1.0
Oct 12 2006 08:39:12
8. Press
to return to the main menu.
