67
Date & Time Used for setting the system date and time.
View Log Used for displaying the event log.
Test Options Used for executing the available test options.
8.1.1 Starting the programming menu
4. In standby mode, the GSM dialer displays the temperature, time and
date.
SD3 +29°C
12:07 01May08
5. Enter your user code (default: 1234). The display now shows the first
menu point.
↑↓ ENT to select
Contact Details
6. Scroll through the menu options using the
keys, or
alternatively press the direct access key to switch to the relevant
function (e.g.
for the View Log).
8.1.2 Ending the programming menu
IMPORTANT:
The programming menu must be exited completely in order for the GSM dialer
to work properly! If the programming menu is still open, then the GSM dialer
will not react to triggers from the inputs!
3. Press the key repeatedly until the display shows the following.
Press [ENT]
to leave the menu
