6. Aansluiting
25. Aansluitklemmen voor ingangen A-D en sabotageaansluiting.
26. Aansluitklemmen voor ingangen G-H, stroomvoorziening en
bekabeling voor de uitgangen.
27. Contacten voor de GSM module.
28. Aansluitklemmen voor de analoge telefoonaansluiting (A/B) en
externe apparatuur (A1/B1).
29. Sabotagecontact
30. Niet in gebruik
31. Luidspreker
32. Microfoon
OPMERKING:
Let er op dat de stroomvoorziening is uitgeschakeld voordat u het apparaat
aansluit!
