Wiring – ABUS AZ6302 Terxon GSM dialer User Manual
Page 59
59
6. Wiring
9. Connector clamps for inputs A-D and tamper wiring
10. Connector clamps for inputs G-H, power supply and output wiring
11. Sockets for the GSM module
12. Connector clamps for the analogue telephone connection (A/B) and
external devices (A1/B1)
13. Tamper contact
14. Not used
15. Loudspeaker
16. Microphone
IMPORTANT:
Make sure that the voltage supply is switched off before wiring!
6.1 Operating voltage (+12 V/0 V)
Connect these clamps to the power supply on the alarm centre (or to an
external power supply when using as a stand-alone device).
