69
Each telephone number can have a maximum length of 16 digits.
During programming, the
key can be used to enter the following
symbols:
- * (star): Adds a * to the number.
- # (hash): Adds a # to the number.
- , (comma): When the GSM dialer is connected to a
telephone system, then a dial pause must normally be added
in order to call external numbers. Adding a comma gives a
dial pause of three seconds (e.g. (0), 0160/12345678)
• Contact type
There are two possibilities when selecting the contact type:
- Voice only
The GSM dialer dials the contact number, plays general and
specific messages and repeats these four times in total.
- Text only
The GSM dialer dials the contact number and forwards the
message to the relevant number.
IMPORTANT:
When entering the telephone number, be aware of local or international dialling
codes regarding the transfer path (analogue or GSM)!
8.3.1.2 Setting the contact details
10. Enter your user code. The initial contact details menu point is then
displayed.
↑↓ ENT to select
Contact Details
Press
to select. Contact 01 is displayed.
11. Scroll through the menu options using the keys, or alternatively
press the corresponding contact number - .
Contact 01
Name 01
