90
Test Options
Confirm by pressing
. The first function is displayed: “Messages”.
6. Access the “Test Supply” option using the scroll keys, or
alternatively press the key.
7. Press . The current voltage is displayed (e.g. 11.8 V).
IMPORTANT:
The input voltage can be between 10.5 V and 28 V. The maximum value on
the display is only 25.5 V.
8. Press
to return to the main menu.
10.6 Test GSM
Using this function, you can see various information regarding GSM operation.
6. Enter your user code. Scroll through the menu options using the
keys, or alternatively press to display the “Test Options” menu
point.
↑↓ ENT to select
Test Options
Confirm by pressing
. The first function is displayed: “Messages”.
7. Access the “Test GSM” option using the scroll keys, or
alternatively press the key.
8. Press . The display now shows “Start Call”.
9. Use the scroll keys and confirm one of the following functions
using :
- Auto Report
Enter the number to be dialled over the GSM network here.
The GSM dialer then establishes the connection as with a
mobile phone.
- Signal Strength
The current signal strength is shown here.
- GSM Number
