ABUS AZ6302 Terxon GSM dialer - Manual (Page 81)

81
Despite the confirmation message, the GSM dialer will
continue to dial all other contact addresses.
10. Press to exit the menu.
8.3.6 Outputs
The GSM dialer has four programmable outputs (OP1-OP4) which can be
controlled remotely and offer a wide range of functions (e.g. switching the
lighting, fans etc.).
8.3.6.1 Output types
• Off
The output remains off continuously.
• Message
The output is activated when a message is waiting and deactivated
when the message is played.
• Remote Access
The output is activated when remote access is started over the
telephone. The output is reset when the remote access is finished.
• Temperature High
The output is activated when the maximum temperature threshold is
reached. The output is deactivated if the temperature falls below the
defined threshold again.
• Temperature Low
The output is activated when the minimum temperature threshold is
reached. The output is deactivated if the temperature rises above the
defined threshold again.
• Listen
This output is activated when the listen mode is activated.
• Talk
This output is activated when the talk mode is activated.
• Line Fault
The output is activated when the line is missing or a fault occurs.
• PSTN In Use
The output is activated when the GSM dialer uses the analogue
telephone line.
• GSM In Use
The output is activated when the GSM dialer uses the GSM network.
