Audio output
Speaker output .............................. 2 mono, 86 dB SPL, 0.1 watt, 0.1 m, half space
Frequency response ........................ 750 Hz to 20 kHz, ±5 dB
Playback format(s) .......................... WAV files: 8 bit PCM, mono, 8 kHz sampling
General
Power ............................................ Supplied by an included power over Ethernet (PoE) adapter or by an optional
external 12 VDC, 1 A power supply
Power supply .................................. External
Input: 100-240 VAC, 50-60 Hz
Output: PoE 802.3af compliant, 48 VDC, 0.35 A, 16.8 watts
Power consumption
Device ..................................... 12.7 watts, 48 VDC (PoE)
Device and power supply ......... 15.3 watts, 100-240 VAC, 50-60 Hz
Power over Ethernet (PoE) input requirements
Complies with PoE 802.3af, class 3
Temperature/humidity .................... Storage: -4 to +140 °F (-20 to +60 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, vents on top rear
Thermal dissipation
Device ..................................... 43.5 BTU/hr
Device and power supply ......... 52.3 BTU/hr
Mounting
Furniture or wall mount ........... Set on tabletop or mount to optional VESA D 75 mm panel mount kit
Adjustment ranges ......................... Tilts through a 45° range
Enclosure type ................................ Plastic
TLP 1000MV and TLP 1000TV • Specifications 38
