The sleep timer determines how long the panel will be inactive before it enters Sleep
mode, when the screen goes dark to save power. The time can be changed from
0
to
50,000
seconds (in 10-second increments). The time that is currently selected is shown
above the buttons.
The screen may need a high level of backlighting for readability when ambient lighting is
high. With low ambient lighting, the backlighting should be low.
Auto Backlight provides a suitable amount of backlighting that is automatically
calculated from the amount of ambient light detected by the light detector.
The Backlight control sets the backlighting manually from
0
to
100
percent, when Auto
Backlight is set to
Off
.
NOTE: When Auto Backlight is set to
On
, changing the percentage of Backlight does
not affect the amount of backlighting.
Wake on Motion activates the panel from Sleep mode when motion is detected near the
unit. Use the on-screen buttons to toggle the Auto Backlight or Wake on Motion options
between
Off
and
On
.
Volume Screen
Main
Volume
Time
Network
Video
Exit
Master: 120
Click: 120
Sounds: 120
Down
Up
Down
Up
Down
Up
Down
Up
Line In: 120
Figure 14.
Volume Screen
Press the
Down
or
Up
buttons to highlight one of the adjustable audio features. Use the
Down
and
Up
buttons to adjust the following settings:
•
Master volume (between
0
and
255
; default
120
) sets the maximum volume for
all the other sound volume settings. For example, if the master volume is set to
200
(approximately 80 percent of maximum), even when the Line In volume is set to
255
(maximum), it will only be equivalent to 80 percent of maximum.
•
Click (between
0
and
255
; default
120
) sets the volume for audible feedback that
accompanies events such as a screen button being pressed.
•
Sounds (between
0
and
255
; default
120
) sets the volume of audio from any audio
file playback.
•
Line In (between
0
and
255
; default
120
) sets the volume of the audio signal received
through the line in from an Extron MTP transmitter.
