Initial
Configuration
and Calibration
This section describes:
• How to Access the Internal On-screen Menus
• The Main , Volume , Time , Network , and Video screens
• The Screen Touch Calibration Screen
How to Access the Internal On-screen Menus
When the TouchLink panel first has power applied, the unit boots up and displays the
opening screen. To access the on-screen menus, press the Menu button (see page 5 for
the
TLP 1000MV or page 10 for the TLP 1000TV ).
The menus open at the Main screen. There are five different screens ( Main , Volume ,
Time , Network , and Video ) that can be selected by pressing the appropriate button at
the left side of the screen.
There is also an
Exit button at the bottom left corner of the screen. Pressing this button
applies and saves any changes and leaves the menu screens.
Main Screen
Main
Volume
Time
Network
Video
Exit
On
On
Down Up
Sleep timer: 300 Sec
Down Up
Backlight: 073%
Auto Backlight
Wake on Motion
PoE
Active
Figure 13. Main Screen
Values can be changed by pressing the buttons to highlight them. Press the Down or Up
buttons to adjust the values or press the Auto Backlight or Wake on Motion buttons to
toggle between
Off and On . The current setting is shown above the buttons.
