This guide includes instructions for an experienced installer to install, configure, and operate
the equipment.
NOTES: • In this manual, the term “PowerCage FOX” refers to either an analog RGB
video or a DVI video unit. Where differences exist between the VGA and DVI
models, the full name of the unit is used.
• In this manual, the term “PowerCage FOX DVI” refers to either the Plus or
non-Plus model, unless a model is specifically named.
About the PowerCage FOX Transmitters and Receivers
The PowerCage consists of several sets of ultra-high performance fiber optic transmitters
and receivers:
•
PowerCage FOX Tx VGA transmitter — Accepts an analog RGB video input, an
audio input, and an RS-232 serial input and outputs a proprietary optical signal on an
LC connector to a PowerCage FOX, FOXBOX, or FOX 500 receiver. It also can receive
a proprietary optical signal from the receiver consisting of the RS-232 return from a
controlled device.
•
PowerCage FOX Rx VGA receiver — Accepts a proprietary optical signal on an LC
connector from a PowerCage FOX, FOXBOX, or FOX 500 transmitter or daisy-chained
PowerCage FOX or PowerCage FOX receiver and outputs analog RGB video, audio, and
RS-232 serial commands. It also can either:
•
Receive an RS-232 return from a controlled device and send it to the transmitter via
a proprietary optical signal, or
•
Output a daisy-chained signal to another receiver.
•
PowerCage FOX Tx DVI Plus transmitter — Accepts a single link of DVI video input
(up to 1920 x 1200 at 60 Hz), an audio input, and an RS-232 serial input and outputs
a proprietary optical signal on an LC connector to a PowerCage FOX Rx DVI Plus or
FOXBOX Rx DVI Plus receiver only. It also can receive a proprietary optical signal from the
receiver consisting of the RS-232 return from a controlled device.
•
PowerCage FOX Tx DVI (non-Plus) transmitter — Similar to PowerCage FOX TX
DVI Plus, but with a lower maximum resolution (1600x1200 or 1080p @ 60 Hz) and a
different proprietary output that is compatible with all PowerCage FOX, FOXBOX, or
FOX 500 receivers.
•
PowerCage FOX Rx DVI Plus receiver — Accepts a proprietary optical signal on an LC
connector from a PowerCage FOX, FOXBOX, or FOX 500 transmitter or daisy-chained
receiver and outputs a single link of DVI video, audio, and RS-232 serial commands. It
also can either:
•
Receive an RS-232 return from a controlled device and send it to the transmitter via
a proprietary optical signal.
•
Output a daisy-chained signal to another receiver.
•
PowerCage FOX Rx DVI (non-Plus) receiver — Similar to the PowerCage
FOX RX DVI Plus, but with lower maximum resolution (1600x1200 or 1080p @ 60 Hz)
and receiving a different proprietary input. Discontinued, but included in this list for
reference only.
