Unit-initiated Messages
When a local event, such as an equipment power-up, occurs, the unit responds by sending a
message to the host. The unit-initiated messages are listed below:
(c) Copyright 2010, Extron Electronics PowerCage FOX
Tx VGA, Vx.xx, 70-699-xx]]
- or -
(c) Copyright 2010, Extron Electronics PowerCage FOX
Rx VGA, Vx.xx, 70-699-xx]]
- or -
(c) Copyright 2010, Extron Electronics PowerCage FOX Tx
DVI, Vx.xx, 70-700-xx]]
- or -
(c) Copyright 2010, Extron Electronics PowerCage FOX Rx
DVI, Vx.xx, 70-700-xx]]
- or -
(c) Copyright 2010, Extron Electronics PowerCage FOX Tx
DVI Plus, Vx.xx, 70-873-xx]]
- or -
(c) Copyright 2010, Extron Electronics PowerCage FOX Rx
DVI Plus, Vx.xx, 70-873-xx]]
The connected unit issues the appropriate copyright message (above) when it first powers
on. Vx.xx is the firmware version number; 70-xxx-xx is the part number of the connected
unit.
Reconfig]
The unit sends the Reconfig message whenever the video input signal to the transmitter is
changed.
1Lnk X1( •2Lnk X1( •RGB X1( •Aud X1( ]
The unit sends the status message whenever a change in the fiber link and video and audio
connection occurs.
Dip X$X$ ]
The unit sends the DIP switch position message whenever a change in the DIP switch
settings on the receiver occurs.
NOTES: • The Dip X$X$ ] message occurs only when the connected receiver is a FOXBOX
unit.
• Only DIP switch 1 (the first X$) has any effect on the system operation. When
the switch is on (up), the receiver is in daisy chain mode.
PowerCage FOX DVI and PowerCage FOX VGA • Remote Control 19
