3. From the drop-down menus on the RS-232 screen, select the appropriate Com port
number and baud rate (the default is 9600).
4. Click OK. The Firmware Loader window appears (see figure 24).
5
Figure 24. Extron Firmware Loader Window
5. Select the PowerCage FOX unit and click File > Open. The Choose Firmware
File screen appears (see figure 25).
6
6
Figure 25. Choose Firmware File Window
6. Navigate to and select the new firmware file. Click Open. The Choose Firmware
File window closes.
NOTE: When downloaded from the Extron website, the firmware is placed in a
subfolder of C:\Program Files\Extron\Firmware.
CAUTION: The firmware file must have a .bin extension. Other file types can cause
the switcher to stop functioning.
PowerCage FOX DVI and PowerCage FOX VGA • Remote Control 34
