Video input — PowerCage FOX Tx DVI, PowerCage FOX Tx DVI Plus
Number/signal type ........................ 1 single link DVI-D (or HDMI*)
Connector ...................................... 1 female DVI-I
NOTE: *Appropriate DVI-D to HDMI cables or adapters are required for HDMI signal input/output. The PowerCage
FOX DVI and DVI Plus boards can be used to distribute HDMI signals if you use a DVI-to-HDMI adapter.
However, when using HDMI signals, these units do not transmit audio and CEC signals.
These boards do not support transmission of DVI signals with High-bandwidth Digital Content Protection (HDCP).
Video output — PowerCage FOX Rx DVI Plus
Number/signal type ........................ 1 single link DVI-D (or HDMI*)
Connector ...................................... 1 female DVI-I
Nominal level ................................. 0.8 Vp-p
Video delay .................................... 1-2 frames
Audio
NOTE: In PowerCage FOX boards, the analog audio signal(s) is (are) digitized in the transmitter, sent through the
fiber cable, and converted back to analog audio in the receiver.
Gain
Range ...................................... Adjustable, -18 dB to +10 dB
Default .................................... Unbalanced output: -6 dB; balanced output: 0 dB
Frequency response ........................ 20 Hz to 20 kHz, ±0.5 dB
THD + Noise
VGA and DVI boards ................ 0.10% @ 1 kHz at nominal level
AV boards ................................ 0.15% @ 1 kHz at nominal level
S/N ................................................. >80 dB at maximum output (unweighted)
CMRR ............................................ 65 dB @ 20 Hz to 20 kHz
Audio bits per sample ..................... 18 bits per channel, 2 channels (L, R)
Sampling rate ................................. 48 kHz
Audio input
Number/signal type ........................ 1 unbalanced stereo or 2 unbalanced mono
Connector ...................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... 10k ohms unbalanced, 20k ohms balanced, DC coupled
Nominal level ................................. +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... +17 dBV, (unbalanced) at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio output
Number/signal type ........................ 1 unbalanced stereo or 2 unbalanced mono
Connector ...................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Nominal level ................................. +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level (Hi-Z) ...................... +19 dBu, unbalanced at 1% THD+N
Maximum level (600 ohms) ............ >+15 dBm, unbalanced at 1% THD+N
Audio delay .................................... 1.5 frames
