Control/remote
Serial control ports
Enclosure ................................. 1 bidirectional RS-232, 2.5 mm mini stereo jack (front panel)
PowerCage FOX boards
Control .............................. 1 bidirectional RS-232, 3.5 mm captive screw connector, 5 pole (uses 3 poles; shared with
the alarm port)
Pass-through ...................... 1 RS-232, 3.5 mm captive screw connector, 5 pole (3 pins are used, “RS-232 Over Fiber”)
Baud rate and protocol
PowerCage FOX boards
Control .............................. 9600 baud, 8 data bits, 1 stop bit, no parity
Pass-through ...................... 9600 to 115,200 baud
Serial control pin configurations
Captive screw connector .......... 1 = Tx, 2 = Rx, 3 = GND
Mini stereo jack ....................... RS-232: tip = Tx, ring = Rx, sleeve = GND
Program control ............................. Extron control/configuration program for Windows
®
Extron Simple Instruction Set (SIS
™
)
General
Power consumption* ..................... 1 or 2* (positive-negative), 100 VAC to 240 VAC, 50-60 Hz; internal, hot-swappable
*
A redundant power supply is optional.
System ..................................... Enclosure without boards: 12.4 watts at 115 VAC, 60 Hz
Each FOX board at 115 VAC, 60 Hz
FOX Tx VGA: 5.68 watts
FOX Rx VGA: 6.54 watts
FOX Tx DVI: 5.67 watts
FOX Rx DVI: 5.50 watts
FOX 3G HD-SDI: 1.84 watts
FOX Tx AV: 6.89 watts
FOX Rx AV: 5.57 watts
Power input requirements for boards . 12 VDC, 1.0 A, supplied by the PowerCage enclosure
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Enclosure: fans, front to back
Boards: convection, within the PowerCage enclosure
Mounting — PowerCage enclosure
Rack mount ............................. Yes
Enclosure type ................................ Metal
Enclosure dimensions
PowerCage enclosure .............. 5.25” H x 17.0” W x 12.25” D (3U high, full rack wide)
13.3 cm H x 43.2 cm W x 31.2 cm D
(Depth excludes connectors on the optional boards. Width excludes rack ears.)
PowerCage FOX boards ........... Fits a double slot opening in a PowerCage enclosure.
Product weight
PowerCage enclosure .............. 11.6 lbs (5.3 kg)
PowerCage FOX boards ........... 1.1 lbs (0.5 kg)
Shipping weight
PowerCage enclosure .............. 13 lbs (6 kg)
Boards ..................................... 2 lbs (1 kg) each
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, FDA Class 1, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%.
NOTE: Specifications are subject to change without notice.
