MKP 2000 Remote Control Panel • Reference Information MKP 2000 Remote Control Panel • Reference Information
Reference Information
A-3 A-2
Specifications
Control/remote — keypad
Serial control port ........................ (2) RS-232 on (2) 3.5 mm, 3-pole captive
screw connectors
Baud rate and protocol ............... Variable (9600 to 115200 baud), 9600 baud
(default), 8 data bits, 1 stop bit, no parity
Serial control pin configurations 1 = TX, 2 = RX, 3 = GND
Ethernet control port ................... 1 RJ-45 female connector
Ethernet data rate ........................ 10/100Base-T, half/full duplex with
autodetect
Ethernet protocol ......................... ARP, DHCP, ICMP (ping), TCP/IP,
Telnet, HTTP, SMTP client
Ethernet default settings ............ Link speed and duplex level =
autodetected
IP address = 192.168.254.253, subnet mask
= 255.255.0.0, default gateway = 0.0.0.0
DHCP = off
Program control ........................... Extron’s Simple Instruction Set (SIS ™ )
Microsoft ® Internet Explorer, Telnet
General
External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external,
autoswitchable; to 12 VDC, 1 A, regulated
Power input requirements ......... 12 VDC, 350 mA
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Rack mount ................................... No, but furniture/wall mountable in a
wall box
Enclosure type .............................. Metal
Enclosure dimensions
Plate ................................... 4.5" H x 4.6" W x 0.1" D (2 gang)
(11.4 cm H x 11.7 cm W x 0.3 cm D)
Enclosure .......................... 2.7" H x 3.4" W x 2.0" D
(6.7 cm H x 8.6 cm W x 5.1 cm D)
Allow at least 1" (2.5 cm) D for connectors
and cable.
(Depth excludes connectors.)
Product weight ............................. 0.4 lbs (0.2 kg)
Shipping weight ........................... 2 lbs (1 kg)
Vibration ....................................... ISTA 1A in carton (International Safe
Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
Part Numbers
MKP 2000 Remote Control Panel Part number
MKP 2000, black 60-682-02
MKP 2000, white 60-682-03
MKP 2000, RAL 9010 white 60-682-05
Included parts
These items are included in each order for an MKP 2000:
Included parts Part number
12 VDC, 1A external power supply 70-055-01
MKP 2000 User’s Manual
MR 200 two-gang mounting brackets
(mud rings) (black, white)
70-519-22, -23
Installation accessories
Accessories Part number
Two-gang “J” box 2.5" deep 980084
Optional accessories
Accessories Part number
PS 123 Rack mountable, multiple output 60-814-01
Power Supply
