Precautions, cont’d
MKP 2000 Remote Control Panel • Quick Start Guide QS-1
Install and set up the MKP 2000 as follows:
Step 1
Turn all of the equipment off, or disconnect it from its power source.
Step 2
Install the cables to and from the control panel in a wall, podium, or
desk. See “Rear Panel and Side Panel Connections” in chapter 2,
“Installation,” for guidelines.
Step 3
Prepare the wall, podium, desk, or other surface to mount the MKP .
See “Preparing the site and installing the mounting bracket (mud
ring) or wall box” in chapter 2, “Installation.”
Step 4
Install the control panel in a wall, podium, desk, or other surface.
See “Mounting the MKP to the mounting bracket (mud ring) or wall
box” in chapter 2, “Installation.”
Step 5
Connect the input and output cables . See “Rear Panel and Side
Panel Connections” in chapter 2, “Installation,” for guidelines.
Step 6
Connect the power supply . See “Power supply wiring” in chapter 2,
“Installation.”
Step 7
Connect power cords and turn on the equipment in the following
order: (1) output devices such as projectors or monitors, (2) the
connected matrix switcher, and (3) input devices such as DSSs or
cable boxes.
Step 8
If necessary, set the control panel’s and matrix switcher’s IP
parameters
. See “Viewing and configuring the IP and MKP setup
parameters” in chapter 3, “Local Operation,” or “System Settings
Page” in chapter 5, “HTML Operation.”
Step 9
If necessary, set the control panel’s RS-232 port for pass-through or
no-pass-through mode, and specify whether the MKP is the primary
device (connected to the switcher) or the secondary device
(connected through another device). See “Viewing and configuring
the IP and MKP setup parameters” in chapter 3, “Local Operation,”
or “System Settings page” in chapter 5, “HTML Operation.”
Quick Start Guide — MKP 2000
