MKP 2000 Remote Control Panel • SIS ™ Operation MKP 2000 Remote Control Panel • SIS ™ Operation
SIS ™ Operation, cont’d
Symbol definitions
= CR/LF (carriage return/line feed) (0x0D 0A)
• = space
X1 = On/off status 0 = off/disable 1 = on/enable
X2 = RS-232 port number 1 = host 2 = switcher
X3 = n = – 1 = redirect serial port data from the specified port to allow
for a transparent pass through mode. The response is returned
with leading zeroes. n = the maximum number of serial ports that
the IP link supports.
X5 is verified at this port.
X4 = Time (in 10 ms increments) to wait for receive data before
releasing the port to another source (min = 1 [10 ms],
maximum = 32767 [32.767 seconds], default = 10 [100 ms]).
X5 = Numerical value (nnnn) to set L (length of message to receive) or
assign as a D (delimiter).
L
= number of byte count (min = 0, max = 32767, default = 0).
D = decimal number for ASCII character (min = 0,
maximum = 00255, default = 00000L).
The numeric value directly precedes the identifier; for example: X5 = “3L”
to specify a 3-byte length or X5 = “10D” to specify an ASCII delimiter of
0A. The identifier, “L” or “D” is case sensitive and must be uppercase.
X6 = Firmware version Bootstrap version (x.xx)
X7 = Verbose firmware version-description-upload date/time. See
page 4-11.
X8 = Voltage 1 (3.3 V), Voltage 2 (12.0 V),
Temperature (degrees Fahrenheit) (xxx.xx)
X9 = Verbose/response mode 0 = no password assigned
1 = verbose mode
2 = tagged responses for queries
3 = 1 and 2 (verbose and tagged)
The default X9 value is 0 for Telnet and 0 for RS-232.
If tagged responses are enabled, all read commands return the constant
string plus the data, the same as setting the value. For example, the MKP
responds Ipn•
X16 to the Esc •CN command.
X10 = Security level 0 = clear/none
11 = user password assigned
12 = administrator password assigned
X11 = Baud rate 300, 600, 1200, 1800, 2400, 3600, 4800,
9600 (default), 14400, 19200, 28800,
38400, 57600, or 115200
X12 = Parity (1st character only) Odd, Even, None (default), Mark,
S pace
X13 = # of data bits 7 or 8 (default)
X14 = # of stop bits 1 (default) or 2
X15 = Name 24 characters maximum.
Upper and lower case alphanumeric
characters and “ ” + – : = / and
spaces are valid.
Using any of the following characters results in an invalid name:
+ ~ , @ = ‘ [ ] { } < > ’ “ ; : | \
and ?.
X16 = Default name Factory default name
(combination of the model name
plus last three pairs of MAC address)
X17 = Time and date (set) MM/DD/YY-HH:MM:SS
MM = month: 01 (Jan.) — 12 (Dec.)
DD = day: 01 through 31
YY = year: 00 through 99
HH = hour: 00 through 24
MM = minutes: 00 through 59
SS = seconds: 00 through 59
X18 = Time and date (read) Day,•DD•Mmm•YYYY•HH:MM:SS
where:
Day = weekday: Mon through Sun
DD = day: 01 through 31
Mmm = month: Jan through Dec
YYYY = year: 2000 through 2099
HH = hour: 00 through 24
MM = minutes: 00 through 59
SS = seconds: 00 through 59
X19 = GMT offset –12.0 through +14.0. Hours and
minutes removed from GMT
X20 = Daylight Savings Time 0 = Daylight Savings Time off/ignore
1 = Daylight Savings Time on
(northern hemisphere)
2 = Daylight Savings Time on
(Europe)
3 = Daylight Savings Time on (Brazil)
X21 = IP address ###.###.###.###
X22 = Hardware (MAC) address ##-##-##-##-##-##
X23 = Connection priority 0 = Primary 1 = Secondary
X24 = Password 12 digits, alphanumeric
Using any of the following characters results in an invalid preset name::
{space} + ~ @ = ‘ ’ [ ] { } < > “ ” ; : | \ and ?.
4-7 4-6
