HD Player Chapter 14: Application Notes
92 Rev. 6.8
• Designate Device 2 as “Slave” (Tcreceive)
• Set both devices to begin playing at a specific time (Tcplayat)
• Start the sequence (Tcstart)
TCP/IP
Command sequence to play file 0 on both players at 01:00:00:00.
NOTE: The Channel numbers (Base Channel) are the same for both devices as the TCP/IP configuration
determines their “addresses”. Refer to Chapter 5, HD Player Configuration for more information on how to set
the Base channel.
Device 1 “Master” Device 2 “Slave”
Playrange 1 0 0 Playrange 1 0 0
Tcgenerate 1 Tcreceive 1
Tcplayat 1 01:00:00:00 Tcplayat 1 01:00:00:00
Tcstart 1 00:59:55:05
RS232
NOTE: The Channel numbers are different for each HD Player. Refer to Chapter 5, HD Player Configuration for
how to set the Base channel.
Device 1 “Master” Device 2 “Slave”
Playrange 1 0 0 Playrange 2 0 0
Tcgen 1 Tcreceive 2
Tcplayat 1 01:00:00:00 Tcplayat 2 01:00:00:00
Tcstart 1 00:59:55:05
