Appendix D: Specifications
Primary Video Output
 Format: RGBHV / YPrPb to SMPTE274M and 296M
 Tri level sync on YPrPb mode as specified by EIA770
Video Connector
15 pin miniature D type socket
Pin Number Name Pin Number Name
1 Red/Pr 9 No Connect
2 Green/Y 10 Sync Ground
3 Blue/Pb 11 No Connect
4 No Connect 12 No Connect
5 No Connect 13 H Sync
6 Red Ground 14 V Sync
7 Green Ground 15 No Connect
8 Blue Ground
Secondary Video Output
 Format: RGBHV / YPrPb to SMPTE274M and 296M
 Tri level sync on YPrPb mode as specified by EIA770
 Support for optional Soft-Edging
15 pin miniature D type socket
Pin Number Name Pin Number Name
1 Red/Pr 9 No Connect
2 Green/Y 10 Sync Ground
3 Blue/Pb 11 No Connect
4 No Connect 12 No Connect
5 No Connect 13 H Sync
6 Red Ground 14 V Sync
