HD Player Appendix D: Specifications
109 Rev. 6.8
 Audio Output Impedance 600 ohms
System Control Aids
 Genlock Controls
o Video Black And Burst 1V p - p
o BNC
o ES-Gen In/Out
o 6 Pin Mini Din
 Timecode Input
o SMPTE, EBU Film (24fps)
o Input Connector Phono Socket
o Input Impedance 600 ohms
o Input Level >100mV p-p
 Timecode Output
o SMPTE, EBU Film (24fps)
o Output Connector Phono Socket
o Output Impedance 600 ohms
o Output Level 1V p-p
 Physical Features
Chassis Weight 27 lbs.
Chassis Dimensions 2 R.U.- 3.5"H x 19"W x 20.75"D
Power, Voltage 110/220 VAC 50/60 Hz Auto Ranging, 250
Watts
Environmental 10 to 40C Ambient, 90% RH non-condensing
Safety Compliance UL, CSA,
