HD Player Chapter 12: Remote Control Protocols
85 Rev. 6.8
Available Player Commands
The following table illustrates the commands that are supported by the HD Player.
Command Action
C6 Play
C5 Pause
E4 Video Off
E3 Video On
E5 Chapter Mode (FrameNo = first file to play in playlist)
E6 Frame Mode
83 Audio On
84 Audio Off
A2 Set stop point for play list. ( FrameNo = last file to play in playlist.)
To use the ES400 protocol to control the HD Player, the following steps should be performed.
 Set up a Playlist containing the files to be used in the installation.
 Send a chapter start with the FrameNo field set to the first chapter to play in the Playlist.
 Send a stop point with the FrameNo Field set to the last chapter to play in the Playlist.
 Send a Play command to play the files.
