HD Player Chapter 11: Remote Control Configuration
70 Rev. 6.8
The Remote Control Methods wizard TCP/IP page
The following window results after selecting the TCP/IP option and clicking Next on the “Method Type” page of
the Remote Control Wizard. There is only one parameter required, the TCP/IP port to use for the connection. It is
usually safe to select ports above the value 2000, although any number can be used in a closed installation.
1. Enter the port number in the window
NOTE: When using ESCAN for control, set Port to 4000 and select MSVPP Protocol.
2. Click Next to advance to the Protocol page.
3. Choose a protocol for this channel from the drop-down list:
 MSVPP
 ES4000 H-Type Parser v1.02
 Telnet Parser v1.06
4. Click on the list to select a Protocol.
5. Click Next to advance
6. Click Finish to end. This will return you to the Remote Control Methods.
Enter port
number 4000
