Hdsdi: ms9200p – Extron Electronics MS9200P User Manual
Page 87
HD Player
Chapter 13: Video Outputs
87
Rev. 6.8
• 1V p–p RGB and YprPb
• 3.3V p-p HSync and Vsync
• Horizontal and Vertical Edge blending 1 – 255 pixels/lines
HDSDI: MS9200P
This is a digital output conforming to the SMPTE292M specification. It is output on the BNC connector.
Currently it supports 1920 x 1080 and 1280 x 720 resolutions in YPrPb color space only. This output can also be
soft edged.
• Horizontal and Vertical Edge Blending 1 – 255 pixels / lines
