IMAGESTAR HD USER GUIDE Appendix A: Control Protocol
I460GB issue 4 Page 73
Preparing HyperTerminal
Start HyperTerminal – Start | All Programs | Accessories | Communications |
HyperTerminal.
The following dialog will appear:
Type in a Name for the new connection (e.g. ImageStar Setup).
Click OK – the following dialog will appear:
In the Connect using list box choose the TCP/IP (Winsock) option.
Type in the IP address of the ImageStar HD in the Host address box.
Type the number 37532 in the Port number box.
Click OK.
HyperTerminal will now try to connect to the ImageStar HD. If the connection is successful
the status bar will show ‘Connected’ on the left hand side:
