IMAGESTAR HD USER GUIDE Section 2: Installation
I460GB issue 4 Page 25
Fitting a Mains Plug
If you are fitting a plug to the unterminated power cord (or replacing an existing plug), you must fit a
plug that:
•
is rated for use with mains voltage
• is equipped with a grounding pin/connection
•
complies with any applicable National or Local electrical regulations
• is fitted with a correctly rated fuse (applicable to UK-style plugs only – see page 26.)
WARNING: Never attempt to fit or use a plug without a ground or earth pin/connection.
Wiring Details
The wires of both mains power cords (supplied with each ImageStar HD) are color-coded as shown in
the table below; be sure to connect your plug in accordance with the following guidelines:
Connect the wire
colored... to the plug terminal identified
with...
Brown ‘L’ or ‘Live’ or ‘Line’
(or colored red or brown)
Blue ‘N’ or ‘Neutral’
(or colored blue or black)
Green & Yellow ‘E ’ or ‘E’ or ‘Earth’ or ‘Ground’
(or colored green or green & yellow)
WARNING — If you are unsure of the connections,
or if the markings in your plug do not match those
given above,
CONSULT A QUALIFIED ELECTRICIAN.
NOTE: The PSU is double-insulated and does not require an earth/ground connection. However, the
earth cable of the mains lead must be connected in the plug.
