Xylem WQL-Cond CONDUCTIVITY DATALOGGERS User Manual
Page 77

WQL-Cond
Working with the database and measurement data
173
ba75822e01
03/2011
Example: Exported
calibration data
opened with MS
Excel
The csv file with the calibration data includes the following information:
z
Sensor name
z
Series number of the logger (SerNo)
z
Calibration ID, so you can allocate the calibration data if there are several
calibration procedures for the exported data
z
Date and time of the calibration
z
Calibration mode (Mode)
z
Calibration temperature (Temp)
z
Cell constant (CellConst)
z
Calibration evaluation
(CalStatus - similar to C
Example: Exported
setting data
opened with MS
Excel
The csv file with the setting data includes the following information:
z
Sensor name
z
Series number of the logger (SerNo)
z
Settings ID (ID) so you can allocate the settings for the exported data
z
Temperature compensation (TempComp)
z
Reference temperature (TRef [°C])
z
Temperature coefficient (LinCoeff [%/K])
z
TDS factor
